Downspout Pipe Roll Forming Machine/Steel Pipe Making Machine Price

Downspout Pipe Roll Forming Machine/Steel Pipe Making Machine Price
Downspout Pipe Roll Forming Machine/Steel Pipe Making Machine Price Downspout Pipe Roll Forming Machine/Steel Pipe Making Machine Price Downspout Pipe Roll Forming Machine/Steel Pipe Making Machine Price Downspout Pipe Roll Forming Machine/Steel Pipe Making Machine Price Downspout Pipe Roll Forming Machine/Steel Pipe Making Machine Price

تصویر بزرگ :  Downspout Pipe Roll Forming Machine/Steel Pipe Making Machine Price

جزئیات محصول:
محل منبع: Botou Hebei China
نام تجاری: HC
گواهی: ISO
شماره مدل: HC100
پرداخت:
مقدار حداقل تعداد سفارش: 1set
قیمت: 25000-49000USD
جزئیات بسته بندی: Main machine is nude,the computer control box is packed by carton box
زمان تحویل: 30days
شرایط پرداخت: 30% deposit by T/T in advance and 70% balance after inspection confirmation before shipment
قابلیت ارائه: 20 sets/month

Downspout Pipe Roll Forming Machine/Steel Pipe Making Machine Price

شرح
Material: DX51 Thickness: 0.4-0.5mm
Diameter: 100mm Power: 4+3KW
Cutting: Fly saw warranty: 1 Year
برجسته:

round downspout machine, pipe roll forming machine

,

pipe roll forming machine

Downspout Pipe Roll Forming Machine/Steel Pipe Making Machine Price



Compositions
3T hydraulic decoiler
1
Feeding→pre-cutting→forming station→Post cutting system
Transmission table
1
Hydraulic station
1
Control desk
1
Elbow machine
1
Profile& Layout
Material of the profile
GI or color steel
Thickness range
0.4-0.7mm
Coil width
444mm
Seaming
6mm
Finished product length
from 500 mm to (at least) 12’000 mm



Downspout Pipe Roll Forming Machine/Steel Pipe Making Machine Price 0Downspout Pipe Roll Forming Machine/Steel Pipe Making Machine Price 1Downspout Pipe Roll Forming Machine/Steel Pipe Making Machine Price 2Downspout Pipe Roll Forming Machine/Steel Pipe Making Machine Price 3

Description:



Downspout Roll Forming Machine  Main parameter

No.

   Main parameter of Downspout Roll Forming Machine

1

Suitable to process

Color steel plate

2

Width of the plate

330mm

3

Rollers

15rows

4

Dimensions

7400*1150*1510mm

5

Power

5.5+4kw

6

Rolling material

high grade 45# steel(plated chrome on surface)

6

Thickness of the plate

0.3-0.6mm

7

Productivity

8-10m/min

8

Diameter of the roller

Φ66mm

9

Voltage

380V 50Hz 3phases

10

Material of the cutting plate

Cr12

11

Hydraulic

40#

12

Processing precision

Within 1.00mm

13

Control system

PLC control

Equipment components: Man-made uncoiler-roll forming machine-computer control system-hydraulic control system-cutting





Application



The roll formed product is mor durable than the tranditional ppc pipe, and not easy to aging.

It will make the project more integrate, and help enhancing the image of all project.

Drainpipe bending machine used for bend the roll formed pipe, to connect the drainpipe and the elbowed pipe.





Competitive Advantage





1. ISO/CE certification

2. 20sets/ month

3. high-speed production

4. easy operate, easy maintain

5.One year free warranty
