Quick details:
1. Warranty: 12 months, After-sales Service Provided: Engineers available to service machinery overseas
2. The color of machine: depend on your required
3. Feeding Material: color steel coils, Payment terms: T/T L/C
Description
This kind of machine has the best quality and the best price. It has accurate measurement and easy operating. We can design and manufacture the special type machine according to the customers’ requirement and we could provide technical guiding, production, installation, debugging and maintenance service to all customers.
Characteristic of Double Layer Roll Forming Machine
1.This Joint Hidden Double Layer Roll Forming Machine can roll form metal roof panels. After roll formed by this Double Layer forming machine, the surface of metal roofing is very smooth and beautiful without any scratch on the surface of roofing.
2.The Double Layer Roll Forming Machine is with fully automatic control system with PLC.
3.Easy operation: Key in the length and quantity on the control panel.
4.We also can do a custom roll forming machine, we can design machine according to your specifications and profile drawings.
Specifications
| Item |
Double Layer Roll Forming Machine |
| Cutting System |
Cutting type |
Hydraulic cutting |
| Cutting Die Material |
Cr12Mov steel, HRC58-62 |
| Cutting power |
3KW |
| CuttingTolerance |
10m+/-1.5mm |
| Encoder |
OMRON Brand |
| Electrical Control Box |
PLC |
PANASONIC Brand |
| Inverter |
YASKAWA Brand |
| Touch screen |
PANASONICE |
| Operation type |
Touch screen & Button |
| Hydraulic Station |
Hydraulic station |
Famous Chinese brand |
| Support Tables |
Table type |
Simple nonpower type |
| Function |
To support the finished panels |
Main Components
| Decoiler / Uncoiler |
1 Unit |
| Feeding Guide |
1 Unit |
| Double Layer Roll Forming Machine |
1 Unit |
| Hydraulic Cutting Device |
1 Unit |
| Hydraulic Station |
1 Unit |
| PLC Computer Control Board |
1 Unit |
| Runout Tables |
2 Units |
Working Flow
Decoiler ---> Fedding Guide ---> Roll Forming ---> Cut-to-length ---> Run out table
Application
Construction, Store Fixture, Metal roof wall cladding, roof wall panel, Metal Roof sheet, trapezoidal roof metal, trapezoidal roofing, trapezoidal panel, corrugated roofing, corrugated panel, metal roof; steel roof.
Advantages
1. We can make and design all kinds of roll forming machine according to customer’s requests.
2. This is a very perfect and durable equipment. We have more than 13 years experiences.
3.This kind of machine has the best quality and the best price. It has accurate measurement and easy operating.
