Automatic 80 to 300 mm adjusting c z purlin interchangeable roll forming machine

نظرات مشتریان
ماشین آسان برای استفاده. رئیس بسیار خوب است

—— آقای آنگولون از اروپا

این سازنده خوب، یک ارتباط خوب انگلیسی است و من ماشین های شما را دوست دارم. این کیفیت خوب و زیبا است!

—— Mr.Mark از آفریقا

تهیه کننده خوب! من تحویل سریع و چرخه تولید سریع خود را می خواهم، با شما تماس می گیرم.

—— Mr.Jack از امریکا

چت IM آنلاین در حال حاضر

Automatic 80 to 300 mm adjusting c z purlin interchangeable roll forming machine

Automatic 80 to 300 mm adjusting c z purlin interchangeable roll forming machine
Automatic 80 to 300 mm adjusting c z purlin interchangeable roll forming machine Automatic 80 to 300 mm adjusting c z purlin interchangeable roll forming machine Automatic 80 to 300 mm adjusting c z purlin interchangeable roll forming machine Automatic 80 to 300 mm adjusting c z purlin interchangeable roll forming machine

تصویر بزرگ :  Automatic 80 to 300 mm adjusting c z purlin interchangeable roll forming machine

جزئیات محصول:
محل منبع: Botou Hebei China
نام تجاری: HC
گواهی: ISO
شماره مدل: HC80-300
پرداخت:
مقدار حداقل تعداد سفارش: 1set
قیمت: 15000-49000USD
جزئیات بسته بندی: Main machine is nude,the computer control box is packed by carton box
زمان تحویل: 30days
شرایط پرداخت: 30% deposit by T/T in advance and 70% balance after inspection confirmation before shipment
قابلیت ارائه: 20 sets/month

Automatic 80 to 300 mm adjusting c z purlin interchangeable roll forming machine

شرح
weight: 5T Length: 8.6m
power: 11+7.5kw thickness: 2-3mm
Warranty: 1 year life time: 10 years above
برجسته:

purlin roll forming machine, rolling forming machine

,

rolling forming machine

Automatic 80 to 300 mm adjusting c z purlin interchangeable roll forming machine



1. The Chart of Process Flow
Decoiling--active feeding--roll forming--measuring length-- cutting to length--product to stand

2. Main Equipment
Decoiler, main forming machine, hydraulic cutting, product stand, hydraulic system, electric system.



Quick Detail:



1. Suitable to process: Color steel plate

2. Width of the plate: 175/465mm

3. Rollers: 13 rows

4. Dimensions: 6.7*1.35*1.51m

5. Power: 11+7.5kw

6. Rolling material: shaft bearing steel(quenching)

7. Thickness of the plate:1.5-3mm

8. Voltage: 380V 50Hz 3phases

9. Material of the cutting plate: Cr12

10. Hydraulic: 40#

11. Processing precision: Within 1.00mm

12. Control system: PLC control



3. Technical Parameters



C shape purline Roll Forming Machine Main parameter

No.

   Main parameter of C Shape Purline Roll Forming Machine

1

Suitable to process

Color steel plate

2

Width of the plate

175/465mm

3

Rollers

13 rows

4

Dimensions

6.7*1.35*1.51m

5

Power

11+7.5kw

6

Rolling material

shaft bearing steel(quenching)

6

Thickness of the plate

1.5-3mm

7

Productivity

8-10m/min

8

Diameter of the roller

Φ80mm

9

Voltage

380V 50Hz 3phases

10

Material of the cutting plate

Cr12

11

Hydraulic

40#

12

Processing precision

Within 1.00mm

13

Control system

PLC control

Equipment components: Man-made uncoiler-leveling-roll forming machine-computer control system-hydraulic control system-punching-cutting



Automatic 80 to 300 mm adjusting c z purlin interchangeable roll forming machine 0Automatic 80 to 300 mm adjusting c z purlin interchangeable roll forming machine 1Automatic 80 to 300 mm adjusting c z purlin interchangeable roll forming machine 2Automatic 80 to 300 mm adjusting c z purlin interchangeable roll forming machine 3

Application:



C purline formed by C purline forming machine,advantages of well compressive strength and flatness; automatioc measureing, cutting and punching; high-level of automation and conveniently installation.
It can be used in the main body stress structure of the large and medium-size enterprises civil construction, like the plant, warehouse, locomotive shed, hangar, exhibition building, theatre, stadiums, roofing load-bearing load and wall surface support of the arbour.





Competitive Advantage



1. ISO certification

2. CE certification

3. PLC Panasonic

4. One year free warranty

5. Low loss, easy operate
